Briefly, this error message usually indicates that Elasticsearch has hit the memory limit that has been set on the system for locked memory, which is a type of memory that is not allowed to be swapped to disk. To resolve this issue, the memory limit needs to be increased by updating the “RLIMIT_MEMLOCK” parameter in the ulimit configuration. This can be done by editing the /etc/security/limits.conf file and adding the following line: “* hard memlock unlimited”.
To easily locate the root cause and resolve this issue try AutoOps for Elasticsearch & OpenSearch. It diagnoses problems by analyzing hundreds of metrics collected by a lightweight agent and offers guidance for resolving them.
This guide will help you check for common problems that cause the log ” Increase RLIMIT-MEMLOCK (ulimit). ” to appear. To understand the issues related to this log, read the explanation below about the following Elasticsearch concepts: bootstrap.
Overview
Elasticsearch has many settings that can cause significant performance problems if not set correctly. To prevent this happening, Elasticsearch carries out “bootstrap checks” to ensure that these important settings have been covered. If any of the checks fail, Elasticsearch will write an error to the logs and will not start. In this guide we cover common bootstrap checks you should know and how to configure your settings correctly to pass the checks successfully.
Bootstrap checks are carried out when the network.host setting in:
network.host: 0.0.0.0
If network host is not set and you use the default localhost, then Elasticsearch will consider the node to be in development mode, and bootstrap checks will not be enforced.
Common issues with bootstrap checks
If you install elasticsearch using RPM or Debian packages (strongly recommended) then most of the important configuration is already done for you, and the only bootstrap checks you are likely to run up against are the following.
Heap size check
The minimum and maximum heap sizes specified in jvm.options (or via environment variables) must be equal to one another.
File descriptors check
Minimum file descriptors must have been set to at least 65535
Memory lock check
There are various methods used to prevent memory swapping, and you must use one of them. The most common is to set in elasticsearch.yml
bootstrap.memory_lock: true
For this to be effective you must give permission to elasticsearch to enable this. There are various ways to do so, depending upon your operating system.
Discovery configuration checks
At least one of the following properties must be configured in elasticsearch.yml to ensure that your node can form a cluster properly:
- discovery.seed_hosts
- discovery.seed_providers
- cluster.initial_master_nodes
Less common bootstrap check issues
If you are not using RPM or debian packages, you may come across the following issues:
Max number of threads check
You must allow your system to create at least 4096 threads. In linux this is done by editing /etc/security/limits.conf and adjusting the nproc setting.
Max file size check
Your system should be able to create unlimited file sizes. In linux this is done by editing /etc/security/limits.conf and adjusting the fsize setting
Max virtual memory check
The system should be able to create unlimited virtual memory for the elasticsearch user.
This is done by editing /etc/security/limits.conf
<user> - as unlimited
Max map count check
The system must be able to use mmap effectively. This is done by running the command
sysctl vm.max_map_count 262144
Other checks
The following checks are also carried out, but are rarely found:
OsX File Descriptor Check Client Jvm Check UseS erial GC Check System Call Filter Check Might Fork Check On Error Check On Out Of Memory Error Check Early Access Check G1GC Check All Permission Check
Log Context
Log “Increase RLIMIT_MEMLOCK (ulimit).” classname is JNANatives.java.
We extracted the following from Elasticsearch source code for those seeking an in-depth context :
"\t" + user + " hard memlock unlimited"
);
logger.warn("If you are logged in interactively; you will have to re-login for the new limits to take effect.");
}
} else {
logger.warn("Increase RLIMIT_MEMLOCK (ulimit).");
}
}
}
static String rlimitToString(long value) {
